Featuring:

  • GaN Technology
  • S-series
    • Sample Ports
  • Compact Design
  • 20 kHz - 1.5 MHz
  • 50 Watts
Unit of Measure

Primary Performance Characteristics

Start Frequency

 N/A 20 kHz

Stop Frequency

 N/A 1.5 MHz

Rated Power (P1dB)

 N/A 50 W

Power Gain

 N/A 47 dB

Gain Flatness

 N/A 1.5 dB

Harmonic Level

 N/A < -25 dBc

Class of Operation

 N/A D/S

Specifications

AC Input

 N/A 110 - 240 VAC

Connectors

 N/A BNC

Operating Temperature

 N/A 0 to 40 ºC

Cooling

 N/A Forced Air Cooling

Form Factor

Weight

 N/A 8 lb3.6 kg

Height

 N/A 3.5 in90 mm

Width

 N/A 9.25 in235 mm

Depth

 N/A 10.9 in275 mm
